Dissolver DISPERMAT® AE

Powerful dissolver up to 7.5 kW with extensive process control

Innovation made in Germany: The dissolver DISPERMAT® AE can also be used with the modular dispersion and fine grinding systems as a vacuum dissolver, bead mill, basket mill, homogeniser and dissolver for high viscous products.

DISPERMAT® type	Power kW	Speed rpm	Torque Nm	Product volume litre
Dissolver DISPERMAT® AE01	0.55	0 ‒ 10000	1	0.25 ‒ 6
Dissolver DISPERMAT® AE02	0.55	0 ‒ 6000	1.8	0.5 ‒ 7
Dissolver DISPERMAT® AE03	1.1	0 ‒ 10000	2	0.25 ‒ 10
Dissolver DISPERMAT® AE04	2.2	0 ‒ 10000	4	0.25 ‒ 15
Dissolver DISPERMAT® AE05	1.1	0 ‒ 6000	3.7	0.5 ‒ 15
Dissolver DISPERMAT® AE06	2.2	0 ‒ 6000	7.4	0.5 ‒ 20
Dissolver DISPERMAT® AE07	3	0 ‒ 6000	10	4 ‒ 30
Dissolver DISPERMAT® AE08	4	0 ‒ 6000	13.7	4 ‒ 40
Dissolver DISPERMAT® AE09	2.2	0 ‒ 3000	15	4 ‒ 45
Dissolver DISPERMAT® AE10	4	0 ‒ 3000	26.5	4 ‒ 70
Dissolver DISPERMAT® AE11	5.5	0 ‒ 3000	37	10 ‒ 120
Dissolver DISPERMAT® AE12	7.5	0 ‒ 3000	50	10 ‒ 150

Repeatable dispersion in laboratory, pilot plant and production

The popular and innovative DISPERMAT® AE dissolvers for laboratory, pilot plant and production are now available with a motor power up to 7.5 kW. The operator has easy access to all of the machine controls from the control panel mounted conveniently on the machine stand. The electric height adjustment as well as the control panel provides access to the complete control dispersion processes. Due to its process control the DISPERMAT provides information about dispersion and milling processes. Process parameters as well as the recorded data can be stored and used again with the software WINDISP 7©.

DISPERMAT® pilot plant and production dissolvers with motors of 3 kW and larger are now equipped with one of the ergonomical stands of the BK‒series. These functional and robust stands are equipped with an integrated safety device and a high‒quality, wear‒resistant linear guides for electric height adjustment. The stands are available in a table and a floor version. The central clamping system is height adjustable and allows the application of the versatile adaptable accessories.

CV ‒ technology

Accessories for the dissolver DISPERMAT^® CA

Flexible. Powerful. Innovative.

Modular dispersion and fine grinding systems for DISPERMAT® dissolver.

The dissolver DISPERMAT® CA can also be used with the modular dispersion and fine grinding systems as a vacuum dissolver, bead mill, basket mill, homogeniser and dissolver for high viscous products.

Bead mill APS		Basket mill TML		Vacuum system CDS		Homogenizer SR		Scraper system ASC

Dispersion containers and dissolver discs

Dissolver		Dispersion containers		Dissolver discs
Dissolver DISPERMAT® AE01		0.25 ‒ 25 litres		Ø = 40 ‒ 125 mm
Dissolver DISPERMAT® AE02		0.25 ‒ 25 litres		Ø = 60 ‒ 150 mm
Dissolver DISPERMAT® AE03		0.25 ‒ 25 litres		Ø = 40 ‒ 150 mm
Dissolver DISPERMAT® AE04		0.25 ‒ 25 litres		Ø = 40 ‒ 175 mm
Dissolver DISPERMAT® AE05		0.25 ‒ 25 litres		Ø = 60 ‒ 175 mm
Dissolver DISPERMAT® AE06		0.25 ‒ 25 litres		Ø = 60 ‒ 175 mm
Dissolver DISPERMAT® AE07		10 ‒ 100 litres		Ø = 70 ‒ 250 mm
Dissolver DISPERMAT® AE08		10 ‒ 100 litres		Ø = 70 ‒ 300 mm
Dissolver DISPERMAT® AE09		10 ‒ 100 litres		Ø = 80 ‒ 300 mm
Dissolver DISPERMAT® AE10		10 ‒ 100 litres		Ø = 80 ‒ 350 mm
Dissolver DISPERMAT® AE11		25 ‒ 250 litres		Ø = 100 ‒ 400 mm
Dissolver DISPERMAT® AE12		25 ‒ 250 litres		Ø = 100 ‒ 450 mm
Accessories for dissolvers		Dispersion containers		Dissolver discs
